Corghi R.E.M.O. Compact Due Wheel Alignment

Every second counts in a busy workshop, but outdated alignment methods slow you down. Struggling with brackets, adapters, and endless adjustments? The R.E.M.O. Compact Due by Corghi eliminates these hassles entirely. As the first-ever contactless alignment system, it streamlines the process by capturing data without touching wheels or rims—no damage, no delays. With a working range of ±18° for total alignment and precise measurements for camber (±10°) and thrust angle (±3°), it provides quick, accurate results that boost efficiency when it matters most.

The Compact Due doesn’t just save time; it redefines ease of use. Its robotized scanning system performs a complete analysis in seconds, enabling technicians to handle multiple tasks simultaneously. Designed for cars and vans, it’s compatible with lifts ranging from 59 to 196 inches in center distance and supports drive-thru or flush-mounted installations.

Wheel Alignment R.E.M.O. Compact Due Specification

Measured Angles Working Range:

Total Alignment (Front and Rear Axles): ±18°

Single Alignment (Front and Rear Axles): ±9°

Camber: ±10°

Thrust Angle: ±3°

Caster Angle: ±24°

Steering Angle Difference: ±24°

Centre Distance: 59"–196"

Compatible Lifts: Corghi X5000, X4300, XT5000, and XT6500 (with optional automatic lift search).

Warranty:

3 Year Parts

1 Year Labor

Key Features

• Installation available through independent installers — ask us for a quote

• Contactless Operation: Prevents rim damage and requires no additional adapters.

• User-Friendly Design: Minimal setup and operation time with intuitive controls.

• Automated Workflow: Performs lift and wheel search autonomously, freeing operators for other tasks.

• Real-Time Data Collection: Immediate and accurate alignment data available during the inspection process.

• Versatile Installation Options: Works with drive-thru, wall-mounted, or flush-mounted configurations.

• Advanced Measurement Tools: Infrared cameras and laser sensors for unmatched precision.

• Increased Efficiency: Allows for faster alignments, reducing downtime and increasing service capacity.

• Environmentally Conscious: Digital manuals and minimal paper use to support sustainability initiatives.

Ideal For

• Professional alignment and suspension shops

• Tire shops expanding into alignment services

• Dealership service departments

• Fleet maintenance operations
